Features | Specifications
- Body: st 37 or Sae 1040
- Gasket: RG5
- Plug: Aisi 316
- Samp: Lead
- Cap: CrNi
| DN | D1 (mm) | D2 (mm) | H2 (mm) | D3 (mm) | H1 (mm) | |
|---|---|---|---|---|---|---|
| HFB 50 | DN50 | 165 | 125 | 20 | 18x4 | 160 |
| HFB 65 | DN65 | 185 | 145 | 20 | 18x4 | 195 |
| HFB 80 | DN80 | 200 | 160 | 20 | 18x8 | 218 |
| HFB 100 | DN100 | 220 | 180 | 22 | 18x8 | 260 |
| HFB 125 | DN125 | 250 | 210 | 22 | 18x8 | 305 |
| HFB 150 | DN150 | 285 | 240 | 24 | 22x8 | 365 |
| HFB 200 | DN200 | 340 | 295 | 26 | 22x12 | 460 |
